HIK Series

HIK Series - Indoor LED Display


HIK series LED solutions deliver unrivalled versatility due to the variety of cabinet configurations available. Integrators specifying the HIK range have access to the broadest range of pixel pitch and aspect ratios options. Perfect for any internal space, these innovative Hisense LED modules include cable-less internal construction and full frontal access for ease of maintenance.

500 nits

With 500 nits maximum brightness the display panels can deliver amazingly vivid imagery anywhere during daytime and nighttime conditions.

160° Wide viewing angle

The extra wide 160° viewing angle is a perfect fit for large groups of people that will view the displays from diverse angles while passing by.

High refresh rate

With uniform color scale and brightness, dynamic performance of LED display could restore the true scenes without any ripples.

Low brightness & High gray level

LED display could reveal more details, including layers and colors, than traditional displays do.

High color calibration

LED display correction technology could uniformly lighten several hundred thousand LED lights, presenting a uniform display effect with the same brightness and color scale.

AOB Admixture on board

AOB Transparent glass on surface enhances the mixed light property with scratch resistance, water-proof & easy to clean.

tab

Dimensions


Connectivity


Pixel Pitch: P1.25
LED Type: SMD1010
Thickness: 53.7mm / 2.11inch

Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W × H mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W × H inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 384 x 432
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs
Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840


Pixel Pitch: P2.0
LED Type: SMD1515 3in1
Thickness: 53.7mm / 2.11inch

Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W×H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W×H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 240 x 270
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs

Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840


Pixel Pitch: P3.75
LED Type: SMD2121 3in1
Thickness: 53.7mm / 2.11inch

Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W x H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W x H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 128 x 144
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs

Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840

Pixel Pitch: P1.5
LED Type: SMD1212

Thickness: 53.7mm / 2.11inch
Module Size (WXH): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W×H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W×H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 320 x 360
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs
Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840


Pixel Pitch: P2.5
LED Type: SMD2121 3in1
Thickness: 53.7mm / 2.11inch

Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W × H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W × H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 192 x 216
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs

Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840


Available Regions
EU
APAC
SA

Pixel Pitch: P1.875
LED Type: SMD1515 3in1

Thickness: 53.7mm / 2.11inch
Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W×H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W×H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 256 x 288
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (lbs/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs

Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840


Pixel Pitch: P3.0
LED Type: SMD2121 3in1
Thickness: 53.7mm / 2.11inch

Module Size (W x H): 240 x 270mm / 9.45 x 10.63inch
Cabinet Dimension (W×H/mm): 480 x 540  / 480 x 270 / 240 x 540
Cabinet Dimension (W×H/inch): 18.90 x 21.26 / 18.90 x 10.63 / 9.45 x 21.26

Cabinet Resolution: 160 x 180
Cabinet Weight (kg/panel): ≤7kg / ≤4kg / ≤4kg
Cabinet Weight (kg/panel): ≤15.44lbs / ≤8.82lbs / ≤8.82lbs

Brightness (Nits): 500 (400-800 Adjustable)
Contrast Ratio: 7000:1
IP Rating: IP50
Viewing Angle): 160˚
Refresh Rate (Hz): 3840
